AIS Nav Symbols
The icons used for AIS Nav symbols appear blue on the chart display
when the symbol is in the `on position'. See the table below.
Physical ATON
Virtual ATON
SAR Aircraft
SAR Vessel (Only when Active)
AIS SART, MOB and EPIRB
Base Station
Off / Missing
ATON Symbols - Physical ATONs are drawn as solid lines, Virtual ATONs
are drawn as dotted lines.
