General-purpose timers (TI
M2/TIM3/TIM4/TIM5)
RM0440
1290/2126
RM0440 Rev 4
The error
assertion is dela
y
ed to
the transition 0
to 1 when in
up-
counting. This is cope with
narrow index pulses in gated
A
and B mode, as shown on
Figur
e
425
below
.
Figure 425
. Up-cou
nting
encoder error detection
MSv45780V1
Channel A
Channel B
IERRF
Index
Channel A
Channel B
IERRF
Index
Counter
5
6
7
0
1
3
2
Counter
5
6
7
0
1
3
2
Error detected
Error asserted
Error detected
Abort (index detection)
