ST STM32G473 User Manual

RM0440 Rev 4 643/2126
RM0440 Analog-to-digital converters (ADC)
724
21.4.23 End of conversion, end of sampling phase (EOC, JEOC, EOSMP)
The ADC notifies the application for each end of regular conversion (EOC) event and each
injected conversion (JEOC) event.
The ADC sets the EOC flag as soon as a new regular conversion data is available in the
ADC_DR register. An interrupt can be generated if bit EOCIE is set. EOC flag is cleared by
the software either by writing 1 to it or by reading ADC_DR.
The ADC sets the JEOC flag as soon as a new injected conversion data is available in one
of the ADC_JDRy register. An interrupt can be generated if bit JEOCIE is set. JEOC flag is
cleared by the software either by writing 1 to it or by reading the corresponding ADC_JDRy
register.
The ADC also notifies the end of Sampling phase by setting the status bit EOSMP (for
regular conversions only). EOSMP flag is cleared by software by writing 1 to it. An interrupt
can be generated if bit EOSMPIE is set.
21.4.24 End of conversion sequence (EOS, JEOS)
The ADC notifies the application for each end of regular sequence (EOS) and for each end
of injected sequence (JEOS) event.
The ADC sets the EOS flag as soon as the last data of the regular conversion sequence is
available in the ADC_DR register. An interrupt can be generated if bit EOSIE is set. EOS
flag is cleared by the software either by writing 1 to it.
The ADC sets the JEOS flag as soon as the last data of the injected conversion sequence is
complete. An interrupt can be generated if bit JEOSIE is set. JEOS flag is cleared by the
software either by writing 1 to it.
Table 167. T
SAR
timings depending on resolution
RES
(bits)
T
SAR
(ADC clock cycles)
T
SAR
(ns) at
F
ADC
= 30 MHz
T
CONV
(ADC clock cycles)
(with Sampling Time=
2.5 ADC clock cycles)
T
CONV
(ns) at
F
ADC
= 30 MHz
12 12.5 ADC clock cycles 416.67 ns 15 ADC clock cycles 500.0 ns
10 10.5 ADC clock cycles 350.0 ns 13 ADC clock cycles 433.33 ns
8 8.5 ADC clock cycles 203.33 ns 11 ADC clock cycles 366.67 ns
6 6.5 ADC clock cycles 216.67 ns 9 ADC clock cycles 300.0 ns
