High-resolution timer
(HRTIM)
RM0440
944/2126
RM0440 Rev 4
Figure 256. DAC triggers for slope c
ompensation
MSv47433V1
CMP1
CMP2
Output 1
hrtim_dac_reset_trigx
hrtim_dac_step_trigx
CMP1
CMP2
Output 1
hrtim_dac_reset_trigx
hrtim_dac_step_trigx
DCDR = 0 (reset on roll-over), DCDT = 0 (step trigger on Compare 2)
DCDR = 1 (reset on output 1 set), DCDT = 1 (step trigger on output 1 reset)
DAC output
DAC output
943
945
