ST STM32G473 User Manual

RM0440 Rev 4 731/2126
RM0440 Digital-to-analog converter (DAC)
773
dac_inc_ch1_trg13 hrtim_dac_step_trg5 Internal signal from on-chip timers
dac_inc_ch1_trg14 hrtim_dac_step_trg6 Internal signal from on-chip timers
Table 183. DAC2 interconnection (continued)
Signal name Source Source type
Table 184. DAC3 interconnection
Signal name Source Source type
dac_hold_ck
ck_lsi or ck_lse (selected in the
RCC)
LSI or LSE clock selected in the
RCC
dac_chx_trg1 (x = 1, 2) TIM1_TRGO
Internal signal from on-chip
timers
dac_chx_trg2 (x = 1, 2) TIM7_TRGO
Internal signal from on-chip
timers
dac_chx_trg3 (x = 1, 2) TIM15_TRGO
Internal signal from on-chip
timers
dac_chx_trg4 (x = 1, 2) TIM2_TRGO
Internal signal from on-chip
timers
dac_chx_trg5 (x = 1, 2) TIM4_TRGO
Internal signal from on-chip
timers
dac_chx_trg6 (x = 1, 2) EXTI9 External pin
dac_chx_trg7 (x = 1, 2) TIM6_TRGO
Internal signal from on-chip
timers
dac_chx_trg8 (x = 1, 2) TIM3_TRGO
Internal signal from on-chip
timers
dac_chx_trg9 (x = 1, 2) hrtim_dac_reset_trg1
Internal signal from on-chip
timers
dac_chx_trg10 (x = 1, 2) hrtim_dac_reset_trg2
Internal signal from on-chip
timers
dac_chx_trg11 (x = 1, 2) hrtim_dac_reset_trg3
Internal signal from on-chip
timers
dac_chx_trg12 (x = 1, 2) hrtim_dac_reset_trg4
Internal signal from on-chip
timers
dac_chx_trg13 (x = 1, 2) hrtim_dac_reset_trg5
Internal signal from on-chip
timers
dac_chx_trg14 (x = 1, 2) hrtim_dac_reset_trg6
Internal signal from on-chip
timers
dac_chx_trg15 (x = 1, 2) hrtim_dac_trg3
Internal signal from on-chip
timers
dac_inc_chx_trg1 (x = 1, 2) TIM1_TRGO
Internal signal from on-chip
timers
dac_inc_chx_trg2 (x = 1, 2) TIM7_TRGO
Internal signal from on-chip
timers
