DMA request multiplexer (DMAMUX) RM0440
428/2126 RM0440 Rev 4
14 EXTI LINE14 30 Reserved
15 EXTI LINE15 31 Reserved
Table 93. DMAMUX: assignment of synchronization inputs to resources
Sync. input Resource Sync. input Resource
0 EXTI LINE0 16 DMAMUX1_ch0_event
1 EXTI LINE1 17 DMAMUX1_ch1_event
2 EXTI LINE2 18 DMAMUX1_ch2_event
3 EXTI LINE3 19 DMAMUX1_ch3_event
4 EXTI LINE4 20 LPTIM1_OUT
5 EXTI LINE5 21 Reserved
6 EXTI LINE6 22 Reserved
7 EXTI LINE7 23 Reserved
8 EXTI LINE8 24 Reserved
9 EXTI LINE9 25 Reserved
10 EXTI LINE10 26 Reserved
11 EXTI LINE11 27 Reserved
12 EXTI LINE12 28 Reserved
13 EXTI LINE13 29 Reserved
14 EXTI LINE14 30 Reserved
15 EXTI LINE15 31 Reserved
Table 92. DMAMUX: assignment of trigger inputs to resources (continued)
Trigger input Resource Trigger input Resource
