Figure 215. Short distance set/reset management for narrow pulse generation
If the set and reset events are generated within the same
t
HRTIM
period, the reset event has
the highest priority and the set event is ignored.
If the set and reset events are generated with an interval below
t
HRTIM
period, across 2
periods, a pulse of 1
t
HRTIM
period is generated.
If the set and reset events are generated with an interval below 2
t
HRTIM
periods, a pulse of 2
t
HRTIM
periods is generated.
If the set and reset events are generated with an interval between 2 and 3
t
HRTIM
periods,
the high-resolution is available if the interval is over 2 complete
t
HRTIM
periods.
MS32277V1
R
S
R
S
R
S
R
S
R
S
R
S
R
S
R
S
R
S
ResetSet
f
HRTIM
clock
Simulaneous set/reset
Reset/set within
the same period
Reset/set within
Reset/set with
interval including 1 x
t
HRTIM
Reset/set within
the same period
Reset/set with
delay <
t
HRTIM
Reset/set with
Reset/set with
interval including 2 x
t
HRTIM
t
HRTIM
> 2 x
t
HRTIM
S
R
Reset/set with
interval including 2 x
t
HRTIM
> 2 x
t
HRTIM
2 successive periods
> 1 x
t
HRTIM
interval including 1 x
t
HRTIM
t
HRTIM
> 1 x
t
HRTIM
t
HRTIM
Set event is discarded
Set event is postponed if interval is < t
HRTIM
Set event is anticipated if interval is > t
HRTIM
Set anticipated
High-Resolution
maintained
