Flexible static memor
y controller (FSMC)
RM0440
538/2126
RM0440 Rev 4
Muxed mode - multiplexed asynchronous a
ccess to NOR Flash memor
y
Figure 65. Muxed read acc
ess waveforms
MSv41685V1
A[25:16]
Memory transaction
NBL[x:0]
NEx
NOE
Data driven by memory
NWE
AD[15:0]
NBLSET
HCLK
cycles
ADDSET HCLK cycles
DAT
AST HCLK cycles
DA
T
AHLD
HCLK cycles
High
ADDHLD
HCLK
cycles
NADV
Lower address
537
539
