Flexible static memory controller (FSMC) RM0440
540/2126 RM0440 Rev 4
WAIT management in asynchronous accesses
If the asynchronous memory asserts the WAIT signal to indicate that it is not yet ready to
accept or to provide data, the ASYNCWAIT bit has to be set in FMC_BCRx register.
If the WAIT signal is active (high or low depending on the WAITPOL bit), the second access
phase (Data setup phase), programmed by the DATAST bits, is extended until WAIT
becomes inactive. Unlike the data setup phase, the first access phases (Address setup and
Address hold phases), programmed by the ADDSET and ADDHLD bits, are not WAIT
sensitive and so they are not prolonged.
The data setup phase must be programmed so that WAIT can be detected 4 HCLK cycles
before the end of the memory transaction. The following cases must be considered:
5:4 MWID As needed
3:2 MTYP 0x2 (NOR Flash memory) or 0x1(PSRAM)
1 MUXEN 0x1
0 MBKEN 0x1
Table 144. FMC_BTRx bitfields (Muxed mode)
Bit number Bit name Value to set
31:30 DATAHLD
Duration of the data hold phase (DATAHLD HCLK cycles for read
accesses, DATAHLD+1 HCLK cycles for write accesses).
29:28 ACCMOD 0x0
27:24 DATLAT Don’t care
23:20 CLKDIV Don’t care
19:16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK).
15:8 DATAST Duration of the second access phase (DATAST HCLK cycles).
7:4 ADDHLD Duration of the middle phase of the access (ADDHLD HCLK cycles).
3:0 ADDSET
Duration of the first access phase (ADDSET HCLK cycles). Minimum
value for ADDSET is 1.
Table 143. FMC_BCRx bitfields (Muxed mode) (continued)
Bit number Bit name Value to set
