AES hardware accelerator (AES) RM0440
1538/2126 RM0440 Rev 4
Refer to Section 2.2 on page 80 for the register boundary addresses.
0x02C
AES_IVR3 IVI[127:96]
Reset value 00000000000000000000000000000000
0x030
AES_KEYR4 KEY[159:128]
Reset value 00000000000000000000000000000000
0x034
AES_KEYR5 KEY[191:160]
Reset value 00000000000000000000000000000000
0x038
AES_KEYR6 KEY[223:192]
Reset value 00000000000000000000000000000000
0x03C
AES_KEYR7 KEY[255:224]
Reset value 00000000000000000000000000000000
0x040
AES_SUSP0R SUSP0[31:0]
Reset value 00000000000000000000000000000000
0x044
AES_SUSP1R SUSP1[31:0]
Reset value 00000000000000000000000000000000
0x048
AES_SUSP2R SUSP2[31:0]
Reset value 00000000000000000000000000000000
0x04C
AES_SUSP3R SUSP3[31:0]
Reset value 00000000000000000000000000000000
0x050
AES_SUSP4R SUSP4[31:0]
Reset value 00000000000000000000000000000000
0x054
AES_SUSP5R SUSP5[31:0]
Reset value 00000000000000000000000000000000
0x058
AES_SUSP6R SUSP6[31:0]
Reset value 00000000000000000000000000000000
0x05C
AES_SUSP7R SUSP7[31:0]
Reset value 00000000000000000000000000000000
0x060-
0x2FF
Reserved
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Res.
Table 327. AES register map and reset values (continued)
