RM0440 Analog-to-digital converters (ADC)

724

21.4.19 Injected channel management

Triggered injection mode

To use triggered injection, the JAUTO bit in the ADC_CFGR register must be cleared.

1. Start the conversion of a group of regular channels either by an external trigger or by

setting the ADSTART bit in the ADC_CR register.

2. If an external injected trigger occurs, or if the JADSTART bit in the ADC_CR register is

set during the conversion of a regular group of channels, the current conversion is

adc_jext_trg8 TIM1_TRGO2 Internal signal from on-chip timers 01000

adc_jext_trg9 TIM8_TRGO Internal signal from on-chip timers 01001

adc_jext_trg10 TIM8_TRGO2 Internal signal from on-chip timers 01010

adc_jext_trg11 TIM1_CC3 Internal signal from on-chip timers 01011

adc_jext_trg12 TIM3_TRGO Internal signal from on-chip timers 01100

adc_jext_trg13 EXTI line 3 External pin 01101

adc_jext_trg14 TIM6_TRGO Internal signal from on-chip timers 01110

adc_jext_trg15 TIM15_TRGO Internal signal from on-chip timers 01111

adc_jext_trg16 TIM20_TRGO Internal signal from on-chip timers 10000

adc_jext_trg17 TIM20_TRGO2 Internal signal from on-chip timers 10001

adc_jext_trg18 TIM20_CC2 Internal signal from on-chip timers 10010

adc_jext_trg19 hrtim_adc_trg2 Internal signal from on-chip timers 10011

adc_jext_trg20 hrtim_adc_trg4 Internal signal from on-chip timers 10100

adc_jext_trg21 hrtim_adc_trg5 Internal signal from on-chip timers 10101

adc_jext_trg22 hrtim_adc_trg6 Internal signal from on-chip timers 10110

adc_jext_trg23 hrtim_adc_trg7 Internal signal from on-chip timers 10111

adc_jext_trg24 hrtim_adc_trg8 Internal signal from on-chip timers 11000

adc_jext_trg25 hrtim_adc_trg9 Internal signal from on-chip timers 11001

adc_jext_trg26 hrtim_adc_trg10 Internal signal from on-chip timers 11010

adc_jext_trg27 hrtim_adc_trg1 Internal signal from on-chip timers 11011

adc_jext_trg28 hrtim_adc_trg3 Internal signal from on-chip timers 11100

adc_jext_trg29 LPTIMOUT Internal signal from on-chip timers 11101

adc_jext_trg30 TIM7_TRGO Internal signal from on-chip timers 11110

adc_jext_trg31 reserved - 11111

Table 166. ADC3/4/5 - External triggers for injected channels (continued)

Name Source Type JEXTSEL[4:0]
