High-resolution timer (HRTIM) RM0440

984/2126 RM0440 Rev 4

27.5.18 HRTIM timer x repetition register (HRTIM_REPxR) (x = A to F)

Address offset: Block A: 0x098

Address offset: Block B: 0x118

Address offset: Block C: 0x198

Address offset: Block D: 0x218

Address offset: Block E: 0x298

Address offset: Block F: 0x318

Reset value: 0x0000 0000

27.5.19 HRTIM timer x compare 1 register (HRTIM_CMP1xR) (x = A to F)

Address offset: Block A: 0x09C

Address offset: Block B: 0x11C

Address offset: Block C: 0x19C

Address offset: Block D: 0x21C

Address offset: Block E: 0x29C

Address offset: Block F: 0x31C

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. Res. Res. Res. Res. Res. Res. REPx[7:0]

rw rw rw rw rw rw rw rw

Bits31:8 Reserved, must be kept at reset value.

Bits 7:0 REPx[7:0]: Timer x repetition period value

This register holds the repetition period value.

This register holds either the content of the preload register or the content of the active register if

preload is disabled.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

CMP1x[15:0]

rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
