1: enable Timer 3 interrupt.
ES4: UART4 interrupt enable bit.
0: disable UART4 interrupt.
1: enable UART4 interrupt.
ES3: UART3 interrupt enable bit.
0: disable UART3 interrupt.
1: enable UART3 interrupt.
ET2: Timer 2 interrupt enable bit.
0: disable Timer 2 interrupt.
1: enable Timer 2 interrupt.
ESPI: SPI interrupt enalbe bit.
0: disable SPI interrupt.
1: enable SPI interrupt.
ES2: UART2 interrupt enable bit.
0: disable UART2 interrupt.
1: enable UART2 interrupt.
INTCLKO (External interrupt and clock output control register)
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
INTCLKO
8FH
-
EX4
EX3
EX2
-
T2CLKO
T1CLKO
T0CLKO
EX4: External Interrupt 4 enabel bit.
0: disable External Interrupt 4.
1: enable External Interrupt 4.
EX3: External Interrupt 3 enabel bit.
0: disable External Interrupt 3.
1: enable External Interrupt 3.
EX2: External Interrupt 2 enabel bit.
0: disable External Interrupt 2.
1: enable External Interrupt 2.
PCA/CCP/PWM Interrupt Control Register
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
CMOD
D9H
CIDL
-
-
-
CPS[2:0]
ECF
CCAPM0
DAH
-
ECOM0
CCAPP0
CCAPN0
MAT0
TOG0
PWM0
ECCF0
CCAPM1
DBH
-
ECOM1
CCAPP1
CCAPN1
MAT1
TOG1
PWM1
ECCF1
CCAPM2
DCH
-
ECOM2
CCAPP2
CCAPN2
MAT2
TOG2
PWM2
ECCF2
CCAPM3
FD54H
-
ECOM3
CCAPP3
CCAPN3
MAT3
TOG3
PWM3
ECCF3
ECF: PCA counter interrupt enable bit.
0: disable PCA counter interrupt
1: enable PCA counter interrupt
ECCF0: PCA module 0 interrupt enable bit.
0: disable PCA module 0 interrupt
1: enable PCA module 0 interrupt
ECCF1: PCA module 1 interrupt enable bit.
0: disable PCA module 1 interrupt
1: enable PCA module 1 interrupt
ECCF2PCA module 2 interrupt enable bit.
0: disable PCA module 2 interrupt
1: enable PCA module 2 interrupt
ECCF3: PCA module 3 interrupt enable bit.
0: disable PCA module 3 interrupt
1: enable PCA module 3 interrupt
CMPCR1 (Comparator Control Register 1)
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
CMPCR1
E6H
CMPEN
CMPIF
PIE
NIE
PIS
NIS
CMPOE
CMPRES
PIE: Comparator rising-edge interrupt enable bit.
0: disable comparator rising-edge interrupt.
1: enable comparator rising-edge interrupt.
NIE: Comparator falling-edge interrupt enable bit.
