STC8A8K64D4 Series Manual
-
- 211 -
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
P0INTE
FD00H
P07INTE
P06INTE
P05INTE
P04INTE
P03INTE
P02INTE
P01INTE
P00INTE
P1INTE
FD01H
P17INTE
P16INTE
P15INTE
P14INTE
P13INTE
P12INTE
P11INTE
P10INTE
P2INTE
FD02H
P27INTE
P26INTE
P25INTE
P24INTE
P23INTE
P22INTE
P21INTE
P20INTE
P3INTE
FD03H
P37INTE
P36INTE
P35INTE
P34INTE
P33INTE
P32INTE
P31INTE
P30INTE
P4INTE
FD04H
P47INTE
P46INTE
P45INTE
P44INTE
P43INTE
P42INTE
P41INTE
P40INTE
P5INTE
FD05H
-
-
P55INTE
P54INTE
P53INTE
P52INTE
P51INTE
P50INTE
P6INTE
FD06H
P67INTE
P66INTE
P65INTE
P64INTE
P63INTE
P62INTE
P61INTE
P60INTE
P7INTE
FD07H
P77INTE
P76INTE
P75INTE
P74INTE
P73INTE
P72INTE
P71INTE
P70INTE
PnINTE.x: Port interrupt enable control bit (n=0~7, x=0~7)
0: disable Pn.x port interrupt function
1: Enable Pn.x port interrupt function
LCM interface configuration register
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
LCMIFCFG
FE50H
LCMIFIE
-
LCMIFIP[1:0]
LCMIFDPS[1:0]
D16_D8
M68_I80
LCMIFIE: LCM interface interrupt enable bit.
0: disable LCM interface interrupt
1: Enable LCM interface interrupt
DMA interrupt enable registers
Symbol
Address
B7
B6
B5
B4
B3
B2
B1
B0
DMA_M2M_CFG
FA00H
M2MIE
-
TXACO
RXACO
M2MIP[1:0]
M2MPTY[1:0]
DMA_ADC_CFG
FA10H
ADCIE
-
-
-
ADCMIP[1:0]
ADCPTY[1:0]
DMA_SPI_CFG
FA20H
SPIIE
ACT_TX
ACT_RX
-
SPIIP[1:0]
SPIPTY[1:0]
DMA_UR1T_CFG
FA30H
UR1TIE
-
-
-
UR1TIP[1:0]
UR1TPTY[1:0]
DMA_UR1R_CFG
FA38H
UR1RIE
-
-
-
UR1RIP[1:0]
UR1RPTY[1:0]
DMA_UR2T_CFG
FA40H
UR2TIE
-
-
-
UR2TIP[1:0]
UR2TPTY[1:0]
DMA_UR2R_CFG
FA48H
UR2RIE
-
-
-
UR2RIP[1:0]
UR2RPTY[1:0]
DMA_UR3T_CFG
FA50H
UR3TIE
-
-
-
UR3TIP[1:0]
UR3TPTY[1:0]
DMA_UR3R_CFG
FA58H
UR3RIE
-
-
-
UR3RIP[1:0]
UR3RPTY[1:0]
DMA_UR3R_CFG
FA60H
UR4TIE
-
-
-
UR4TIP[1:0]
UR4TPTY[1:0]
DMA_UR4R_CFG
FA68H
UR4RIE
-
-
-
UR4RIP[1:0]
UR4RPTY[1:0]
DMA_LCM_CFG
FA70H
LCMIE
-
-
-
LCMIP[1:0]
LCMPTY[1:0]
M2MIE: DMA_M2M (Memory-to-Memory DMA) interrupt enable bit.
0: disable DMA_M2M interrupt
1: enable DMA_M2M interrupt
ADCIE: DMA_ADC (ADC DMA) interrupt enable bit.
0: disable DMA_ADC interrupt
1: enable DMA_ADC interrupt
SPIIE: DMA_SPI (SPI DMA) interrupt enable bit.
0: disable DMA_SPI interrupt
1: enable DMA_SPI interrupt
UR1TIE: DMA_UR1T (UART 1 send DMA) interrupt enable bit.
0: disable DMA_UR1T interrupt
1: enable DMA_UR1T interrupt
UR1RIE: DMA_UR1R (UART 1 receive DMA) interrupt enable bit.
0: disable DMA_UR1R interrupt
1: enable DMA_UR1R interrupt
UR2TIE: DMA_UR2T (UART 2 send DMA) interrupt enable bit.
0: disable DMA_UR2T interrupt
1: enable DMA_UR2T interrupt
UR2RIE: DMA_UR2R (UART 2 receive DMA) interrupt enable bit.
0: disable DMA_UR2R interrupt
1: enable DMA_UR2R interrupt
UR3TIE: DMA_UR3T (UART 3 send DMA) interrupt enable bit.
0: disable DMA_UR3T interrupt
1: enable DMA_UR3T interrupt
UR3RIE: DMA_UR3R (UART 3 receive DMA) interrupt enable bit.
