137
4 Adjusting knitting machine
4.1 Basic settings
Changing a value The values are changed by means of a virtual keyboard. If a value can be
changed, a keyboard bar which allows a value to be entered, is displayed
in the title bar of the menu.
Numerical keyboard
Changing a value:
1. Tap the corresponding field. The setting window appears, for example:
"Yarn carrier" window
2. The keyboard bar appears in the title bar. Use it to carry out the
changes.
3. Confirm input.
6 Actions for yarn carrier plunger, fabric take-down, comb take-down
and auxiliary take-down
7 Call up "Stitch length" window
8 Additional yarn carrier distance for fully fashion knitting
Area Explanation
Element Function
End setting process without saving changes
Undo a change, the previous value is displayed again
End setting process and save changes
Input elements
