Adjusting knitting machine 4
Basic settings 4.1
138
Setting up of the knitting
systems
The stitch tension, needle action, yarn carrier and jacquard line are
displayed for every knitting system. The corresponding menu is opened if
the yarn carrier, stitch tension or jacquard line is touched.
"Change NP value" window
Area Display Change
1 Stitch tension (rear knitting system) Value can be changed at
indirect specification
(NP6=9.2)
2 Needle action (rear knitting system)
3 Number of the knitting system
4 Yarn Carrier Yarn Carrier Correction
Yarn carrier stopping position
5 Needle action (front knitting system)
6 Stitch tension (front knitting system) Value can be changed at
indirect specification
(NP5=9.2)
7 Jacquard line
