4 Adjusting knitting machine
4.2 Advanced adjustments
6. With the lower adjusting lever (4) bend carefully (without using force)
the yarn carrier tip to the front and to the rear.
7. Check the adjustment.
For that purpose move the yarn carrier over the "needle cross".
The adjustment is correct, if the lower end of the yarn carrier tip is
located exactly in the center of the needle cross.
Position of the yarn carrier tip:
A Inner yarn carrier (track 7, 8 or 9)
B Outer yarn carrier (track 1, 2, 15 or 16)
