Setup Data 5

Setup2 Editor 5.4

242

The Input Helper for Yarn

Carriers (YLC tab)

Element Function

Enter yarn carrier specification

Example: 3A

Delete entry

Move cursor: one character to left

Move cursor: one character to the right

Confirm input
