251
5 Setup Data
5.4 Setup2 Editor
YC / YCI (tab) Yarn carrier corrections for autarkic yarn carriers (ADF).
Explanation Value range
YC Direct yarn carrier correction
Collapse (reduced display)
Expand (expanded display)
YCI Yarn carrier correction index YCI1 to
YCI20
Collapse (reduced display)
Expand (expanded display)
Y Corrections of yarn carrier 1A to 16B
Ka Correction value for the yarn carrier (on
the left) if the autarkic yarn carrier is
positioned in its own color field.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
Kb Correction value for the yarn carrier (on
the right) if the autarkic yarn carrier is
positioned in its own color field.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
K<I>a Correction value for yarn carrier (on the
left) if the autarkic yarn carrier is
positioned outside its own color field.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
K<I>b Correction value for yarn carrier (on the
right) if the autarkic yarn carrier is
positioned outside its own color field.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
mm] Correction of insertion position for
autarkic yarn carriers (ADF)
Positive value: following yarn carrier
Negative value: leading yarn carrier
Minimum value: -100
Maximum value: 100
Step width: 0,1 mm
mm] Correction of the insertion angle for
autarkic yarn carriers (ADF)
Positive value: Steeper yarn angle
Negative value: Flatter yarn angle
Minimum value: -2.5
Maximum value: 5.0
Step width: 0,1 mm
MSEC Carriage speed if this yarn carrier is used
(technical fabrics).
