Stoll CMS ADF-3 - Page 361

361
7 Repairing the knitting machine
7.7 Entering the data of the needle selection displacement manually
Controlling the data of the
needle selection
displacement
1. Call up the "Service" menu from the "Main menu".
2. Call up "Basic Settings" menu.
3. Open the "Needle bed parameters" window.
4. Call up the additional function keys in the "Needle bed parameters"
window.
5. Open the "Needle bed parameters 2" window.
6. Compare the displayed values with the values on the machine data
sheet.
7. If the values are not identical to the data of the needle selection
displacement enter them manually (see next section).
8. Call up the "Main menu".
Entering the data of the
needle selection
displacement manually
Call up "Additional function keys"
Open the "Needle bed parameters 2" window
Call up "Main menu"
Key Function
Keys for controlling the data for the needle selection displacement
Key Function
Continue on to the next window
Call up "Additional function keys"
Open the "Needle bed parameters 2" window
Confirm input
return to the "Needle bed parameters" window
Keys for entering the data for the needle selection displacement
