098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 221
Chapter 4 Provisioning
Provisioning the Non-PTP Outputs
Provisioning the T1/E1 Output
The set output command is used to provision the output characteristics for the
T1/E1 port. See Figure 4-21. The
set port-control command is used to
provision the T1/E1 port as an output and to provision the signal type as T1 or E1,
as shown in Figure 4-13.
4 0x4 0CFF 0x7 86
5 0x4 0CFF 0x7 88
6 0x4 78FF 0x4 90
7 0x8 7CFF 0xD 92
8 0x8 7CFF 0xD 94
9 0x8 7CFF 0xD 96
10 0x8 7CFF 0xD 98
11 0x8 7CFF 0xD 100
12 0xB 10FF 0xA 102
13 0xB 10FF 0xA 104
14 0xF 30FF 0xF 106
15 0xF 30FF 0xF 108
16 0xF 30FF 0xF 110
Note: A license is required to enable T1/E1 functionality.
Table 4-6. PQL for Frequency Outputs - Converted to SSM or clockClass (Continued)
From
Output
PQL
Output SSM
Option 1
E1 and SyncE
Output SSM
Option 2
T1
Output SSM
Option 2
SyncE
Output PTP
clockClass
G.8265.1
