Page #307 background image
098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 307
Appendix B Specifications and Factory Defaults
Specifications
10 MHz Output
1PPS Output Signal Specifications
Clocks
Table B-20. TimeProvider 2300/2700 10 MHz Output Signal Specifications
Parameter Specification
Signal type LV TTL square wave
Duty cycle 50% +/- 5%
Connector type BNC male, shared with 1PPS output
Impedance 50
Amplitude 15 dBm to17 dBm
Jitter and Wander When tracking GNSS: per G.811 (PRS/PRC)
When tracking E1/T1/SyncE: per G.812
When tracking PTP GM w/o freq: per G.8261
Table B-21. TimeProvider 2300/2700 1PPS Output Signal Specifications
Parameter Specification
Signal type LV TTL square wave
Duty cycle 50% +/- 5%
Connector type BNC male, shared with 10 MHz output
Impedance 50
Amplitude 15 dBm to17 dBm
Rise Time < 10 ns
Jitter and Wander When tracking GNSS: per G.811 (PRS/PRC)
When tracking E1/T1/SyncE: per G.812
When tracking PTP GM w/o freq: per G.8261
