334 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Appendix C Installing GNSS Antennas
Antenna Coaxial Cable
Antenna Coaxial Cable
Table C-2. LMR-400 Antenna Coaxial Cable Accessories
Part Number Description
121-32212-00-2 Type N (male) connector for LMR-400 cable
12813080-000-0 Crimp Kit for LMR-400 or equivalent (10 ea. N-Type connector,
crimp tool, weatherproof tape)
Contact your sales office for available cable lengths and specific cable item number.
Table C-3. LMR-400/LMR-400FR Antenna Coaxial Cable Specifications
Cable Type Measured Loss DC Resistance ()
Type Center
Conductor
LMR-400 17.25 dB per 100 m
5.25 dB per 100 ft.
Shield 0.00165 per ft.
Center 0.00139 per ft.
Shield 0.005 per m
Center 0.0045 per m
0.109 inch Solid
(0.27686 cm or
(0.0602 cm
2
)
