24 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Chapter 1 Overview
Overview
Overview
The Symmetricom® TimeProvider™ 2700 is an IEEE 1588 Precision Time Protocol
(PTP) Grandmaster scaled and optimized for deployment to support small cells and
to meet the stringent phase timing and synchronization requirements of 4G/LTE
networks.
With an integrated GNSS receiver (GPS or GLONASS) the TimeProvider 2700
meets requirements of the ITU-T G.8272 standard for a Primary Reference Time
Clock (PRTC). It can operate in Synchronous Ethernet (SyncE) networks, and
supports from 8 to 64 PTP clients. The TimeProvider 2700 offers the optional
capability to accept a PTP input or T1/E1 input to complement and backup the
GNSS signal. Additional output capabilities allow it to support legacy frequency
timing applications.
The TimeProvider 2300 Advanced Boundary Clock accepts PTP input. It can
operate in Synchronous Ethernet (SyncE) networks, and supports from 8 to 64 PTP
clients. The TimeProvider 2300 offers the optional capability to accept T1/E1 input
to complement and backup the PTP input signal. Additional output capabilities allow
it to support legacy frequency timing applications.
TimeProvider 2300/2700 Features
IEEE 1588 Precision Time Protocol Grandmaster
ITU-T G.8265.1, Telecom-2008, and Default (optional) profiles
Multi-Sync Enabled Boundary Clock (licensed on TP 2700)
GNSS (GPS and GLONASS), Primary Reference Time Clock (PRTC)
(TP 2700 only)
Support for 8 to 64 PTP clients
SyncE Input and Output
2 Gigabit Ethernet PTP/SyncE Interfaces (SFP or RJ45)
E1/T1 Input or Output (optional)
10 MHZ or PPS, and TOD output
1 Gigabit Ethernet MGMT Port
1 EIA-232 Serial (Craft) Port
LED indicators
Compact 1 RU Footprint
CLI management and SNMP traps
DC or AC power
HTTP/HTTPS/SSL Network Support
