Appendix B Specifications and Factory Defaults
Factory Defaults
PTP DSCP Value 0 0 to 63
PTP State Enable Enable | Disable
PTP Max Number of Clients max 1 to max
(max # of clients determined
by the PTP client license
PTP Dither Disable Enable | Disable
PTP Two Step Disable Enable | Disable
PTP Client Timeout 300 10 to 3600 seconds
PTP Multicast Announce Receipt
Timeout
3 2 to 10
PTP Multicast VLAN ID 0 0 to 4094,
0 is used to signify no VLAN
PTP Multicast Sync Interval
(2^y)
0–7 to 7
PTP Multicast Announce Interval
(2^y)
1–4 to 4
Table B-42. T1/E1 Output Port Parameters
Description Default Value Value Range
T1/E1 Input/Output Port Output Input | Output
T1/E1 Output Port State Enable Enable | Disable
T1/E1 Input Port Priority 3 1 - 10
T1/E1 Input Port Configured
PQL
31 - 16
T1/E1 Input Port
User-Configured PQL State
Disable Enable | Disable
T1/E1 Output Port Signal Type T1 T1 | E1
E1 Output Port Frame Type CCS CCS | CAS | freq2048khz
E1 Output Port CRC State Enable Enable | Disable
E1 Output Port SSM State Enable Enable | Disable
E1 Output Port 1 SSM Bit All 4 | 5 | 6 | 7 | 8 | All
Table B-41. PTP Grand Master Multicast Parameters (Default Profile) (Continued)
Description Default Value Value Range
