292 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Appendix B Specifications and Factory Defaults
Specifications
Specifications
This section provides the specifications for the TimeProvider 2300/2700 input and
output signals.
Mechanical
Environmental
Table B-1. TimeProvider 2300/2700 Mechanical Specifications
Parameter Description
Mounting 19 in. or 23 in. Rack
Rack Mounting For front mounting location unit protrudes 0.77 in /
1.956 cm
See
Figure 2-2 and Figure 2-3 for drawings with
detailed chassis dimensions.
Width 17.24 in. / 438 mm
Height 1.73 in. / 44 mm; 1 RU
Depth 9.3 in. / 237 mm
10.07 in. / 256 mm - including connectors on faceplate
Weight
AC model
DC model
7.6 lb. / 16.72 kg
8.1 lb. / 17.82 kg
Table B-2. TimeProvider 2300/2700 Environmental Specifications
Parameter Description
Operating Temperature -40ï‚° to 65ï‚°ï€ C, -40ï‚° to 149ï‚° F ï€ OCXO [startup > -20ï‚°C (-4ï‚°F)]
-5ï‚° to 55ï‚°ï€ C, 23ï‚° to 131ï‚° F ï€ Rubidium oscillator
Storage Temperature -40ï‚° to 70ï‚°ï€ C, -40ï‚° to 158ï‚° F
Operating Humidity 5% to 95% RH, maximum, w/condensation
Acoustic Noise 0 dBA (negligible due to passive cooling)
