298 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Appendix B Specifications and Factory Defaults
Specifications
DS1 Input
E1 Input
PTP Input
Table B-7. TimeProvider 2300/2700 DS1 Input Signal Specifications
Parameter Specification
Signal Type ANTSI T1.403. G.703 Section 5 Framed T1
or Format: D4, ESF, 1544 kHz
Impedance 100 ohms
Connector Type RJ48c, balanced pair (shares with E1)
Table B-8. TimeProvider 2300/2700 E1 Input Signal Specifications
Parameter Specification
Signal Type G.703 Section 9 Framed E1
or G.703 Section 13 2048 kHz
Format CAS or CCS, CRC4 enable/disable
Impedance 120 ohms
Connector Type RJ48c, balanced pair (shares with DS1)
Table B-9. TimeProvider 2300/2700 PTP Input Signal Specifications
Parameter Specification
Ports ETH1
Connector Type
S1
R1
Ethernet Small Form-factor Pluggable (SFP)
Optical 1000 Base-X
RJ45, 100/1000 Base-T
PTP Profile Telecom-2008
