098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 55
Chapter 2 Installing
Signal Connections
TOD Connection
The TimeProvider 2300/2700 features a RJ-45 port for the TOD output signal, as
shown in Figure 2-16. See Table 2-5 for pin-outs for this RJ-45 connector. See Tabl e
2-6 for TOD default parameters.
See Table B-16, Table B-17, Table B-18
, and Table B-19 in Appendix B for TOD
format details.
6NC
7NC
8NC
Table 2-5. 1PPS+TOD Port Pin-Outs - RJ45 Connector
Pin Signal Comment
1 422_1_Pos 1PPS
2 422_1_Neg 1PPS
3 No Connection Default state is open (high impedance)
4 No Connection Default state is open (high impedance)
5 No Connection Default state is open (high impedance)
6 No Connection Default state is open (high impedance)
7 422_2_Pos TOD time information
8 422_2_Neg TOD time information
Table 2-4. T1/E1 Output Port Pin-Outs - RJ-48C Connector
Pin Signal
