098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 317
Appendix B Specifications and Factory Defaults
Factory Defaults
Auto Negotiation Enable Enable | Disable
Speed All 100M | 1000M | All
Table B-36. PTP Grand Master ETH2 Port VLAN Parameters - Fixed Index (1
ï€
16)
Description Default Value Value Range
Address No VLAN configured Valid IPv4 Address
Mask No VLAN configured Valid IPv4 Mask
Gateway No VLAN configured Valid IPv4 Address
ID 0
(not visible in VLAN table)
2 to 4094
Priority 0 0 to 7
Mode Disable Enable | Disable
State Disable Enable | Disable
Table B-37. PTP Grand Master ETH2 Port VLAN Parameters - Non-Fixed
Description Default Value Value Range
Ethernet Port Address No VLAN configured Valid IPv4 Address
Ethernet Port Mask No VLAN configured Valid IPv4 Mask
Ethernet Port Gateway No VLAN configured Valid IPv4 Address
ID 0
(not visible in VLAN table)
2 to 4094
Priority 0 0 to 7
Mode Disable Enable | Disable
State Disable Enable | Disable
Table B-35. PTP Grand Master ETH2 Port IP Parameters (Continued)
Description Default Value Value Range
