Page #301 background imageLoading...
Page #301 background image
098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 301
Appendix B Specifications and Factory Defaults
Specifications
DS1 Output
E1 Output
1PPS+TOD Output
Table B-13. TimeProvider 2300/2700 DS1 Input Signal Specifications
Parameter Specification
Signal Type ANTSI T1.403. G.703 Section 5 Framed T1
or Format: D4, ESF, 1544 kHz
Connector Type RJ48c (shares with E1)
Impedance 100 ohms
Coupling Transformer coupled
Extra framing Isolated pulse for testing
Table B-14. TimeProvider 2300/2700 E1 Output Signal Specifications
Parameter Specification
Type G.703 Section 9 Framed E1
or G.703 Section 13 for 2048 kHz
Format CAS or CCS, CRC4 enable/disable
Connector Type RJ45 (shares with DS1)
Impedance 120 ohms
Coupling Transformer coupled
Table B-15. TimeProvider 2300/2700 1PPS+TOD Output Signal Specifications
Parameter Specification
Port Name TOD
Connector Type RJ45
Signal Level RS-422
