098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 203
Chapter 4 Provisioning
Provisioning Input Parameters
Provisioning Input Parameters
Setting PTP Input Client Parameters
The TP 2300/2700 supports the Telecom-2008 unicast profile for the PTP client.
Use the “set ptp client” command to provision the PTP profile and master VLAN
parameters for the client, as shown in Figure 4-9. Use the
set ptp client config
command to provision the master table parameters for the client, as shown in Figure
4-10. Use the
set ptp client config command to provision the PTP input client
parameters for the ETH1 port, as shown in Figure 4-10 and Figure 4-10. See Table
3-5 for descriptions of PTP client parameters for the Telecom-2008 profile.
Figure 4-9. Set PTP Client Command Hierarchy (partial)
Note: All master IP addresses configured in the master table
must be reachable, either by being in the same subnet as the
port (ETH1) IP address, or through a configured gateway. If
either of the master addresses is not reachable through the
network configuration, then neither of the masters will be
utilized for PTP even if one master is correctly addressed.
