296 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Appendix B Specifications and Factory Defaults
Specifications
Serial Port
MGMT Port
Input Signals
GNSS Receiver
Table B-4. TimeProvider 2300/2700 Serial Port Specifications
Item Description
Connector Type 9-pin, female D connector
Connector Label Craft
Interface RS-232, data terminal equipment (DTE)
Baud Rate 57.6 Kbps
Data Bits 8
Parity Bit None
Stop Bits 1
Flow Control None
Table B-5. TimeProvider 2300/2700 LAN Port Specifications
Connector Description
MGMT RJ-45 (10/100/1000 Base-T) - Supports telnet
sessions
and SSH sessions over TCP/IP.
Table B-6. TimeProvider 2700 GNSS Input Signal Specifications
Parameter Specification
Signal Type GNSS L1
Gain Between 15 dB and 30 dB, including gain of antenna
and loss of cable
Frequency GPS: 1575.42 MHz
GLONASS: 1602 MHz
