314 TimeProvider 2300/2700 User’s Guide 098-00564-000 Revision A3 – July, 2013
Appendix B Specifications and Factory Defaults
Factory Defaults
Table B-30. GNSS Input Port Parameters
Description Default Value Value Range
GNSS Priority - Time 1 1 to 10
GNSS Priority - Frequency 1 1 to 10
GNSS Use Configured PQL -
State
Enable Enable | Disable
GNSS Configured PQL - Time 1 1 to 16
GNSS Configured PQL - Freq. 1 1 to 16
GNSS Antenna Cable Delay 0 0 to 999 ns
GNSS Position Mode Auto Auto | Manual
GNSS Position Lat -
N37:22:43.425
Long -
W121:55:34.815
Elevation - 13.7m
LAT = Ndd:mm:ss.ss or
Sdd:mm:ss.sss
0 to 90 degrees
LONG = Eddd:mm:ss.ss or
Wddd:mm:ss.sss
0 to 180 degrees
HEIGHT= ±hhhh.h height in
meters,
-10000.0 to 10,000.0 meters
GNSS Elevation Mask 10 5 to 60 degrees
Step size is 1 deg
GNSS Track Mode GPS GPS | GLONASS
| GLONASS-GPS
Table B-31. PTP Client ETH1 Port IP Parameters
Description Default Value Value Range
IP Address 192.168.1.12 Valid IPv4 Address
IP Mask 255.255.255.0 Valid IPv4 Mask
Gateway 0.0.0.0 Valid IPv4 Address, special
value of 0.0.0.0 is used for
no gateway
State Enable Enable | Disable
