098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 309
Appendix B Specifications and Factory Defaults
GNSS Antenna Kits Specifications
.
Weight 150 grams
Environmental
Operating Temperature -40 to +85 ï‚°C
Vibration 3G, 10 to 200 Hz sweep
Humidity IP67 compliant
ESD Protection 15 kV air discharge
Electrical
Power +2.3 to +10 VDC, up to 15 ma at +2.3 VDC
Polarization Right-hand circular
LNA Gain, 26 dB antenna 26 dB +/- 2 dB
LNA Gain, 40 dB antenna 40 dB +/- 2 dB
Bandwidth 1575 to 1606 MHz
Noise Figure 2.5 dB typical
Output Impedance 50 ohms
Table B-25. GNSS Antenna Kits
Antenna Kit Part Number
Delay
(ns)
Net
Gain
(dB)
TP 2700 GNSS (GPS/GLONASS) Antenna Kit, 20 meter 990-13180-020 76 22.5
TP 2700 GNSS (GPS/GLONASS) Antenna Kit, 40 meter 990-13180-040 154 19.0
TP 2700 GNSS (GPS/GLONASS) Antenna Kit, 70 meter 990-13180-070 271 26.9
TP 2700 GNSS (GPS/GLONASS) Antenna Kit, 150 meter 990-13180-150 575 22.5
TP 2700 GNSS (GPS/GLONASS) Antenna Kit, 230 meter 990-13180-230 902 22.5
Note: The cable delay and gain values correspond to the cable kit
being used in its entirety without modification. The values assume
that a splitter is not used. Splitters are not recommended.
Table B-24. GNSS Antennas with Internal Low-Noise Amplifier Specifications
Characteristic Specification
