098-00564-000 Revision A3 – July, 2013 TimeProvider 2300/2700 User’s Guide 59
Chapter 2 Installing
Applying Power to the TimeProvider 2300/2700
ETH1 - R1 Ethernet Port 1 - RJ45 (r1)
LEDs on the Ethernet connector
Left Amber Flashing - Activity on link for 100M
Left Amber On - Link established for 100M
Left Amber Off - No link for 100M
Right Green Flashing- Activity on link for 1000M
Right Green On - Link established for 1000M
Right Green Off - No Link for 1000M
ETH2 - S2 Ethernet Port 2 - SFP (S2)
LEDs on the Ethernet connector
Green - Activity on link for 1000M
Off - No Activity
ETH2 - R2 Ethernet Port 2 - RJ45 (R2)
LEDs on the Ethernet connector
Left Amber Flashing - Activity on link for 100M
Left Amber On - Link established for 100M
Left Amber Off - No link for 100M
Right Green Flashing- Activity on link for 1000M
Right Green On - Link established for 1000M
Right Green Off - No Link for 1000M
Table 2-8. LED Descriptions (Continued)
