TELECOR VOICE SERVER FLOW CHARTS
This part of the “Reference” section provides a series of flow charts, outlining the procedures
followed by the Telecor Voice Server for handling inbound and outbound calls, and transfers. Also
charted is how calls to Auto Attendants and ACDs are processed. These charts are to be used in
conjunction with the detailed descriptions found in the “VS1 Editor” section of this guide.
Inbound CO Call
CO Call
CO Tar get #1
Rings is > 0
CO Tar get #3
Rings is > 0
CO Tar get #4
Rings is > 0
Ring Target #1
Ports f or specif ied
number of rings
Ring Target #2
Ports f or specif ied
number of rings
Ring Target #3
Ports for specified
number of rings
Ring Target #4
Ports f or specif ied
number of rings
Was Call
Answ ered?
Was Call
Answ ered?
Was Call
Answered?
Was Call
Answered?
Complete
yes
no
CO Target #2
Rings is > 0
no
no no
nono
no
yes
yes
yes
yes
yes yes yes
yes yes
no
