Interpreting Day SMDR Data
The Day SMDR data is recorded in five comma-delimited fields into the day.dlm file. Each field
records the following information about a port: extension description, device type, extension
number and call pick-up group. This information is used by a Call Accounting program to generate
SMDR reports (Detail, Summary and ACD) with sensical information rather than just the port
number.
Field Description Type Maximum Width
1 Port Number Numeric 4
2 Extension Description Character 30
3 Device Type Numeric 2
4 Extension Number Numeric 4
5Group Numeric 4
Port
Number
Extension
Description
Port
Type
Extension
Number
Call Pick-
upGroup
1CO Line 12-1
2CO Line 22-1
3CO Line 32-1
4CO Line 42-1
5 Receptionist 2 0
6 Norm Stenger 2 100
7 Walter O'Riley 1 101 1
8 Board Room 6 102 1
Codes for Port Type (Field 3) of Day SMDR Data
0=No Connection
1=Standard Phone
2=CO Line
3=3 Line Feature Phone
4=Reserved 1
5=Call
6=Modem, Fax
7=Display Phone
8=Attendant
9=Connect/CTIM
10=Connect/PCOM
Note Call (Code 5) and 3 Line Feature Phone (Code 3) are reserved for backwards
compatibility.
Day SMDR data
imported into a
spreadsheet
