VS1 Installation, Configuration & Operating Guide 73
Uploading new settings and reloading changes
After the above settings have been configured, use your current connection method (such as the
default on-site connection) to upload the new settings to the customer TVS and reload the changes.
See “Tel-Site Basic Operation” on page 76.
Hardware Setup
Prior to making the necessary hardware changes, ensure the TVS is configured to support the TVS
Modem Shares a CO Line connection (see page 70).
The diagram below shows the hardware setup for a shared CO connection. The CO line from the
telephone company demarc is run to the line jack of the TVS modem. Another telephone cord is run
from the phone jack of the TVS modem to a CO port on the PEU.
Note: It is important that you share one of the least-used CO lines. Usually a CO line in the
middle of the inbound hunt group and outbound line pool is best.
TVS Modem Shares a
CO Line (off-site
access)
Tel-Site Setup
Tel-Site must be set up so that it can dial the phone number of the CO Line plugged into the line
jack of the TVS modem. It then must automatically dial the extension number set up with DISA and
the associated DISA account to complete the connection. Complete the following steps:
1. From the File menu, click Site Selection.
• The Site Selection window appears.
2. Select the site from the Site Name column.
3. Click Edit Site.
• The Connection dialog box appears.
4. If an RSA password is required to enable the Tel-Site modem to communicate with the TVS,
enter it in the RSA password text box. See “Remote System Access (RSA) Password” on page
78 for more information.
