250 Reference
Start Num: This box must contain 7 digits. Enter the DID start number of your block of
numbers preceded by the necessary amount of placeholders. Telecor recommends using 1 for
the placeholder since it is then obvious that they are not part of the routing number.
End Num: This box must contain 7 digits. Enter the DID end number of your block of numbers
preceded by the necessary amount of placeholders. Telecor recommends using 1 for the
placeholder since it is then obvious that they are not part of the routing number.
Example (for a 4-digit DID): Start Number 1114001 End Number 1114100
Start Time: Enter the start time that you want this block of numbers to recognized. Use
standard military time format.
End Time: Enter the end time that you want this block of numbers to recognized. Use standard
military time format.
Note: The End Time must not come before the Start Time.
Days: Select the days of the week that you want this block of numbers to be recognized.
4. Specify the Target Ext and Target Mode.
Target ext: Enter the target extension for the DID Routing Entry.
Fixed Target Mode: means that all numbers in the block are targeted to the same extension.
For example, assigning 1114001–1114100 to Extension 103 means that 4001 goes to Extension
103; 4002 goes to Extension 103, and so on.
Note: DNIS numbers are usually assigned as individual numbers and not in related blocks. DNIS
numbers can only be routed in the Fixed Target Mode.
Relative Target Mode: means that each number in the block is targeted to a specific,
individual extension. For example, if the Start Num is 1114001 and the Target Extension is 101,
the number 4001 routes to extension 101, 4002 routes to extension 102, 4010 routes to
Extension 110, and so on.
• To assign one number to a specific extension, type the same number in the Start Number
and End Number text boxes. In the Target Ext text box enter the target extension, and
then select Fixed as the Target Mode.
5. Click the Save button in the toolbar.
• The settings for the DID/DNIS Routing Table appear in the list box above.
6. Validate the table by clicking the Validate this Pane button in the toolbar.
