voltage:
+5V(3A) ,+12V(1A) ,-12V(0.5A) ,+24V(0.5A) , and its common terminal is COM(0V) . The
connection
of TOMATECH-PB2 power box toTAC-1002T XS2 interface has been done for its delivery
from factory, and
the user only need to connect it to a 220V AC power in using.
+ 5 V
+ 5 V
0 V
+ 5 V
+ 1 2 V
0 V
- 1 2 V
0 V
+ 2 4 V
Fig. 2-24 system power interface CN1
2.7 I/O Interface Definition
Note!
The I/O function significances of the unlabelled fixed addresses of
thisTAC-1002T/TAC-100XT-V turning machine CNC system are
defined by PLC programs (ladders), and they are defined by the
machine builder when matching with a machine, please refer to the
manual by the machine builder.
The fixed address I/O function not be marked are described for
TAC-100XT PLC. The described contents without other special
explanation are also applied toTAC-1002T-V.
Chapter 2 Definition and Connection of Interface Signal
319
Ⅲ Connec
Subscript
Address
Function
Explanation
21 ~ 24
0V
Power interface
Controller internal 0V
18 ~ 20
25 ~ 28
empty
empty
empty
1
X0.0
SAGT
Protective door detection signal
2
X0.1
SP
External pause
3
X0.2
THAN
External tool clamp/unclamp
4
X0.3
DECX
X axis homing decelerate signal
