TOMATECH TAC-100XT User Manual

TOMATECH AUTOMATION
44
X3.7
LMI5
5
th
axis overtravel input
tion
Fig.2-25 input
Ⅲ Connection
Fig.2-26 output interface
(CN62)
2.7.1 Input signal
Input signal means the signal from machine to CNC, when this signal is through on with
+24V,
the input is active; when it is off with +24V, the input is inactive. The contact of input signal
at machine
side should meet the following conditions:
2.7.2 Output signal
The output signal is used for the machine relay and indicator, if it is through on with 0V,
the output function is active; if it is off with 0V, the output function is inactive. There are 36
digital volume outputs that they all have the same structure in I/O interface as shown in
Fig. 2-29:
Subscript
Address
Function
Explanation
17 ~ 19
26 ~ 28
0V
Power interface
Controller Internal 0V
20 ~ 25
+24V
Power interface
Controller Internal 24V
1
Y0.0
COOL
Coolant output
2
Y 0.1
M32
Lubrication output
3
Y 0.2
Reserve
4
Y 0.3
M03
Spindle anticlockwise rotation (forward)
5
Y 0.4
M04
Spindle clockwise rotation (reversal)
6
Y 0.5
M05
Spindle stop
7
Y 0.6
SCLP
Spindle clamp
8
Y 0.7
SPZD
Spindle brake
