TOMATECH TAC-100XT User Manual

TOMATECH AUTOMATION
X, U, Z, W range: ±99999999× least input increment；
Can omit one or all command addresses X(U), Z(W). The coordinate values of starting
point and end point are the same when omitting one command address; the end point and
the starting point are in the same position when all are omitted. X, Z are valid, and U, W
are invalid when X,U, Z and W are in the same one block. X, U, Z, W rang is referred to
Table 1-2 of Section 1.4.1,
unit: mm//inch.
Command path:
Ⅰ Programming
The respective rapid traverse speed of X, Z is defined by the system parameter No.022,
No.023,
and their traverse speed can changed by rapid override key on the machine control panel.
Example: The tool rapidly traverses to B from A as Fig. 3-2.
Fig. 3-2
