01/02
6-34
8825/8830 Printer
Installation Procedure
General Procedures
Figure 11 Reinstalling the Sump Shield
19. ( Figure 12): Reinstall the Top Shield, rear edge first.
Figure 12 Reinstalling the Top Shield
CAUTION
Ensure that the Developer Module is kept close to the Printer frame during reinstallation in
order to avoid damage to the Toner Dispenser Motor.
20. (Figure 13 ): Reinstall the Developer Module.
1
Position the Sump Shield
2
Reinstall the edges of the shield
under the edge on the housing
1
Reinstall the Top Shield
2
Reinstall the
screws
3
Tighten the
screws
To Next Page
