Specifications
9
9.3 Model Specifications (200 V Class)
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 447
*3 Assumes the value at the rated output current. The input current rating changes when the power supply transformer, input reactor,
wiring connections, or power supply impedance change.
*4 The rated output capacity is calculated with a rated output voltage of 208 V.
*5 The rated output capacity is calculated with a rated output voltage of 220 V.
Table 9.3 Rating (200 V Class)
Model 2056 2070 2082 2110 2138
Maximum Applicable Motor
Output (kW)
HD1
*1
11 15 18.5 22 30
ND1
*2
15 18.5 22 30 37
Maximum Applicable Motor
Output (HP)
HD1
*1
15 20 25 30 40
ND1
*2
20 25 30 40 50
Input
Rated Input
Current
*3
(A)
HD1 (AC) 58.2 78.4 96 82 111
HD1 (DC) 71 96 118 101 136
ND1 (AC) 78.4 96 114 111 136
ND1 (DC) 96 118 139 136 167
Outputs
Rated Output
Capacity (kVA)
HD1
*4
17.9 22.9 28.6 33.5 43.8
ND1
*5
21.3 26.7 31.2 41.9 52.6
Rated Output
Current (A)
HD1 47 60 75 88 115
ND1 56 70 82 110 138
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds
• ND: 110% of the rated output current for 60 seconds
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD1: 8 kHz without derating the drive capacity.
ND1: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• Advanced Open Loop Vector Control (AOLV) and EZ Open Loop Vector Control
(EZOLV): 120 Hz
• Closed Loop V/f Control (CL-V/f), Closed Loop Vector Control (CLV), Advanced
Open Loop Vector Control for PM (AOLV/PM), and Closed Loop Vector Control
for PM (CLV/PM): 400 Hz
• V/f Control (V/f), Open Loop Vector Control (OLV), and Open Loop Vector
Control for PM (OLV/PM): 590 Hz
Measures for
Harmonics
DC Reactor External options Standard internal characteristics
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3, C2/C3
Factory option
• Models 2xxxB: There is a category C3 EMC filter in the drive.
• Models 2xxxC: There is a category C2 EMC filter in the drive.
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
HD1 24.2 32.6 39.9 34.1 46.1
ND1 32.6 39.9 47.4 46.1 56.5
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*3 Assumes the value at the rated output current. The input current rating changes when the power supply transformer, input reactor,
wiring connections, or power supply impedance change.
*4 The rated output capacity is calculated with a rated output voltage of 208 V.
