Figure 94 • Release the Dancer Spring
Caution • Wear protective eyewear when installing or removing E-rings, C-clips, snap
rings, springs, and mounting buttons. These are under tension and could fly off.
See Figure 94. Release the dancer spring from the dancer spring stop
1
Dancer spring stop
2
Dancer spring
1
2
