Corrective Maintenance
Outer Guard Rewind
356
14207L-001 A
ZM400/ZM600 Maintenance Manual
8/9/07
4.
5.
Remove the flat and wave washers from the
rewind spindle shaft.
Figure 216 • Remove the E-ring and W
ashers
Caution •
Wear protective eyewear when installing or removing E-rings, C-clips, snap
rings, springs, and mounting bu
ttons. These are under ten
sion and could fly off.
See
Figure
216
. Remo
ve the e-ring secu
ring the rewind spindle.
1
Rewind spindle
2
E-ring
3
Wa
v
e
w
a
s
h
e
r
4
Flat washer
1
2
3
4
355
357
