Zebra ZM400 Series

411
Corrective Maintenance
Wireless Option
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
3. See Figure 269. Install the two standoffs from the kit into the main logic board (MLB).
Figure 269 • Install the Standoffs
1
Main logic board (MLB)
2
Wireless board mounting standoffs (2)
3
Standoff mounting holes (2)
1
2
3
