A-30

Agilent 7500 ICP-MS ChemStation Operator’s Manual

Appendix

Execution of Dead Time Calibration

This section describes how to execute the Dead Time Calibration by using erbium

(Er) solution. Indium (In) is also available for dead time calibration.

For executing the Dead Time calibration, follow the next procedure.

NOTE Dead time calibration needs to be performed after replacement of the electron

multiplier.

1 Perform a new EM and Adjust Discriminator tune.

2 Prepare the calibration standard solution for Dead Time Calibration.

For example, 50ppb Er and 1ppm Er.

3 Select the Use Dead Time Calibration in the ICP-MS Configuration dialog box.

The

ICP-MS configuration dialog box is displayed by selecting Start >> Programs

>> ICP-MS Chemstation >> Configuration >> Miscellaneous

ICP-MS Configuration Dialog Box
