Agilent Technologies 7500 ICP-MS User Manual

A-39
Agilent 7500 ICP-MS ChemStation Operator’s Manual
Appendix
Appendix E Precautions on
Using the ICP-MS ChemStation
with the LC/GC ChemStation
Installing the ICP-MS ChemStation and the LC/GC ChemStation to a single PC
makes it possible to execute an LC/GC ChemStation method in an ICP-MS Chem-
Station sequence.
Connecting the Agilent 7500 and the LC/GC
Connect the Agilent 7500 and the LC/GC as shown below:
• Use an APG remote cable to connect the Agilent 7500 and LC/GC.
• Connect the PC and the ICP-MS or LC/GC with a LAN cable via a switching
Hub. In general, use straight cables only. If the Hub is AUTO-MDIX-compatible,
either straight or crossover cables may be used.
Refer to the instruction manual for each instrument for information on making
connections. Note that Agilent 7500 ICP-MS or LC/GC Instruments with the GPIB
interface cannot be synchronized with the LC/GC ChemStation.
Switching Hub
LAN Cable
LC/GC ChemStation
APG Remote Cable
LC System
ICP-MS ChemStation
Agilent 7500
PC
