APPEAR AS Confidential 132/352
6.4.1.5 Configuring an EMM Generator (EMMG) Channel
To establish a connection to an EMM Generator (or Private Data Generator), go to Scrambler → SCS →
EMMG/PDG node in the Navigation Tree, enter appropriate values and click Add.
The following information is displayed:
Logical port representing the connection to the EMMG – assigned automatically. This
number is used internally as well as for generating alarms.
For reference in the GUI only
EMM transfer connection can be either of the below
-TCP
-TCP/UDP
-UDP
IP address of the EMMG to be connected to. If the value 0.0.0.0 is used, the unit will
accept a connection from any IP address. When multiple sources are trying to connect,
it is first come first serve.
TCP port for the EMMG to connect to
CA vendor specific sub ID
Status of the EMMG/PDG connection, either OPEN or NOT CONNECTED.
To change an, EMMG channel connection, click on the existing EMMG entry and enter the new configuration.
